Fall Protection For Ultra Seam Roofs
Posted by Howie Scarboro - CEO Fall Protection Distributors, LLC on Feb 12th 2026
See the Roof Anchor Compatibility Chart for Ultra Seam Standing Seam Metal Roofing.
Who Is Ultra Seam?
Ultra Seam is a leading architectural roofing manufacturer, providing high-quality, engineered solutions for commercial, residential, and industrial applications nationwide. They have facilities in Fairbanks, Alaska; Mesa, Arizona; Rancho Cucamonga, California; and Honolulu, Hawaii.
Focusing on engineering excellence, Ultra Seam manufactures an extensive range of standing seam panels in 22-gauge, 24-gauge, and 26-gauge galvanized or Galvalume steel. Their comprehensive product line includes:
- Standing Seam Panels: Profile options include the US-100, US-150, and the structural US-200.
- Specialized Systems: Flush Wall panels, Soffit panels, and Ultra Dek or Double Lok structural systems.
- Components: Custom-engineered clips, fasteners, flashings, and trim tailored to meet the specific needs of each project.
Their systems can outlast traditional materials, with lifespans of 40 to 70 years and the ability to withstand wind gusts up to 100 mph. Their panels feature high-performance Kynar 500® paint finishes backed by 30- to 40-year warranties.
The SSRA Component System & Expansion Tools
The SSRA system is a professional-grade modular platform designed to adapt to the diverse needs of Ultra Seam job sites:
- SSRA1 Seam Anchor: The foundation of the system. This patented and non-penetrating anchor provides a certified tie-off point rated at 5,000 lbs.
- SSRA2 Adjustable Roof Jack Adapter: Mounts directly to the SSRA1 to support 10-foot wooden walk boards. It is fully adjustable to match the roof pitch and seam height.
- SSRA3 Anchor Plates: Heavy-duty aluminum spanner plates for mounting temporary horizontal lifeline systems.
- 100-Foot SSRA Temporary HLL Kit: A complete and non-penetrating solution for temporary projects. Restrict use to roof pitches of 4:12 or less.
- 120-Foot Super Anchor Permanent HLL Kit: A long-term solution featuring 5-inch riser posts and 120 feet of galvanized cable. It attaches with non-penetrating seam clamps. Restrict use to roof pitches of 4:12 or less.
- The Ridge Pro Steep Assist: The premier "First-Man-Up" tool for roof pitches between 6:12 and 12:12.
Why Are Compatible Seam Anchors Critical For Standing Seam Roofs?
Standing-seam metal roofs offer exceptional weather resistance, but their unique "floating" design requires specialized fall protection. Unlike traditional roofing, which uses exposed fasteners, Ultra Seam panels use concealed fasteners and clip systems to accommodate thermal expansion and contraction.
Using the wrong fall protection anchor on an Ultra Seam roof can lead to:
- Structural Damage: Anchors that require drilling create hidden water leaks.
- Voided Warranties: Penetrating the metal surface typically voids the manufacturer's weather-tightness warranty.
- Catastrophic Failure: Anchors not specifically designed for the rib profile may slip during a fall event.
The safest solution is a non-penetrating, seam-mounted anchor system that clamps securely to the seams. These OSHA-compliant anchors provide a 5,000-lb certified tie-off point while preserving the roof's watertight seal and architectural integrity.
Proper Attachment: Set Screws and Torque Requirements
Your safety and the SSRA1 anchor's certified holding power depend on correct set screw application based on the material gauge of your Ultra Seam panels:
- Cupped-Tip Stainless Steel Set Screws: Use these exclusively on 22-gauge steel panels, and torque them to 90 inch-pounds for a secure, non-penetrating lock.
- Nylon-Tipped Set Screws: Use these on 24-gauge steel panels to achieve certified holding power. Torque them to 180–200 inch-pounds for maximum strength.
- Maintenance: Treat nylon tips as consumables and replace them after 3 to 5 uses to maintain the most reliable seam attachment.
US-200 Mechanically Seamed Panels (SSRA Compatible 22/24 ga. Steel)
The Ultra Seam US-200 panel is a high-performance, mechanically seamed metal roofing system designed for long-term durability and weather resistance. With its 2-inch seam height, this panel provides exceptional strength. It is ideal for low-slope and long-span applications where superior water tightness and structural integrity are critical. See the Roof Anchor Compatibility Chart for 22 Gauge and 24 Gauge US-200 Mechanically Seamed Ultra Seam Standing Seam Metal Roofing.
Available in 22-gauge and 24-gauge steel, zinc, copper, and aluminum, the US-200 panel offers extensive material choices to meet various project requirements. Panel widths range from 12 to 18 inches, providing flexibility for a wide range of architectural and structural applications. The mechanically seamed side lap ensures that all clips and fasteners are fully enclosed, providing the most weather-tight seal. The seams are locked using hand- or power-seamers, securing the roof system against harsh weather conditions and extreme wind uplift.
Fall Protection for US-200 Panels
Ensuring worker safety while maintaining the integrity of Ultra Seam's US-200 panel requires the use of compatible, non-penetrating fall protection solutions. Because this panel is mechanically-seamed, the best fall protection methods depend on the substrate and the panel's configuration.
- For 22-gauge and 24-gauge steel panels: The SSRA1 Seam Anchor, SSRA2 Adjustable Roof Jack, and SSRA3 Anchor Plate provide a secure and non-penetrating fall protection system. The SSRA1 Seam Anchor clamps directly to the panel's standing seams without drilling, preserving the roof's structural and weather-tight integrity. When combined with the SSRA2 Adjustable Roof Jack, workers can install 10-foot wooden walkboards, creating a stable platform for installation, repairs, and maintenance tasks. The SSRA3 Anchor Plate allows for the setup of the 100-Foot SSRA Temporary HLL Kit, ensuring continuous fall protection for multiple workers. The SSRA1 also supports the installation of the 120-Foot Super Anchor Permanent HLL Kit.
- For all other substrates: The Ridge Pro Steep Assist is the preferred fall protection option for roofs with slopes between 6:12 and 12:12. The Ridge Pro is attached over the roof peak, providing a secure tie-off point for workers without requiring penetrations or seam clamps.
US-175LS Lok-Seam Snaplock Panels (SSRA Compatible 22/24 ga. Steel)
The Ultra Seam US-175LS Lok-Seam panel is a snaplock standing seam metal roofing system that combines ease of installation with exceptional weather resistance. With a 1.75-inch standing seam rib height, this panel locks into place with concealed fasteners. It does not require mechanical seaming, significantly reducing installation time and labor costs. Manufactured in 22-gauge and 24-gauge steel, aluminum, zinc, stainless steel, and copper, the US-175LS panel offers flexibility for a range of architectural and structural applications. See the Roof Anchor Compatibility Chart for 22 Gauge and 24 Gauge US-175LS Lok-Seam Snaplock Ultra Seam Standing Seam Metal Roofing.
Fall Protection for US-175LS Panels
Selecting non-penetrating anchors for Ultra Seam's US-175LS Lok-Seam panels ensures worker safety while preserving the roof's structural integrity.
- For 22-gauge and 24-gauge steel panels: The SSRA1 Seam Anchor, SSRA2 Adjustable Roof Jack, and SSRA3 Anchor Plate provide a non-penetrating and OSHA-compliant fall protection system. The SSRA1 Seam Anchor clamps securely onto the panel's standing seam ribs without drilling, preserving the roof's weather-tight seal. When paired with the SSRA2 Adjustable Roof Jack, the system allows the use of 10-foot wooden walkboards. The SSRA3 Anchor Plate is compatible with the 100-Foot SSRA Temporary HLL Kit, providing continuous fall protection for multiple workers. The SSRA1 is also compatible with the 120-Foot Super Anchor Permanent HLL Kit. Since some snaplock seam designs vary, performing a test fit before installation is strongly recommended.
- For all other substrates: The Ridge Pro Steep Assist is the best fall protection option for roof slopes between 6:12 and 12:12. This non-penetrating system hooks over the roof peak, providing a secure tie-off point without requiring seam clamps.
US-150 Mechanically-Seamed Panels (SSRA Compatible 22/24 ga. Steel)
The Ultra Seam US-150 panel is a mechanically-seamed standing seam metal roofing system designed for superior weather-tightness, structural integrity, and long-term performance. With a seam height of 1.5 inches, this panel is ideal for projects requiring enhanced strength and long panel runs. It is particularly suitable for low-slope and large-scale roofing applications. See the Roof Anchor Compatibility Chart for 22 Gauge and 24 Gauge US-150 Mechanically-Seamed Ultra Seam Standing Seam Metal Roofing.
Fall Protection for US-150 Panels
- For 22-gauge and 24-gauge steel panels: The SSRA1 Seam Anchor, SSRA2 Adjustable Roof Jack, and SSRA3 Anchor Plate offer a comprehensive fall protection system. The SSRA1 Seam Anchor clamps securely onto the standing seam ribs without drilling, preserving the panel's weather-tight integrity while providing a strong tie-off point for fall arrest systems. When combined with the SSRA2 Adjustable Roof Jack, the system supports 10-foot wooden walkboards. The SSRA3 Anchor Plate is compatible with the 100-Foot SSRA Temporary HLL Kit. The SSRA1 is also compatible with the 120-Foot Super Anchor Permanent HLL Kit.
- For all other substrates: The Ridge Pro Steep Assist is the best fall protection option for roof slopes between 6:12 and 12:12. This system hooks securely over the roof peak, eliminating the need for penetrations or seam clamps.
US-150LS Lok-Seam Snaplock Panels (SSRA Compatible 22/24 ga. Steel)
The Ultra Seam 1.5-inch US-150LS Lok-Seam panel is a versatile standing seam metal roofing and siding system for exceptional durability and weather-tight performance. Available in 11.5-inch or 16-inch widths, this high-strength panel is 22-gauge or 24-gauge steel, aluminum, zinc, stainless steel, and copper. See the Roof Anchor Compatibility Chart for 22 Gauge and 24 Gauge US-150LS Lok-Seam Snaplock Ultra Seam Standing Seam Metal Roofing.
Fall Protection for US-150LS Panels
- For 22-gauge and 24-gauge steel panels: The SSRA1 Seam Anchor, SSRA2 Adjustable Roof Jack, and SSRA3 Anchor Plate offer a secure and non-penetrating fall protection system. The SSRA1 Seam Anchor clamps directly to panel seams without drilling, providing a strong tie-off point while preserving the roof's watertight integrity. When paired with the SSRA2 Adjustable Roof Jack, the system supports 10-foot wooden walkboards. The SSRA3 Anchor Plate is compatible with the 100-Foot SSRA Temporary HLL Kit. The SSRA1 also supports the 120-Foot Super Anchor Permanent HLL Kit.
- For all other substrates: The Ridge Pro Steep Assist is the best fall protection option for 6:12- to 12:12-pitch roofs.
US-150CL Clip-Loc Snaplock Panels (SSRA Compatible 22/24 ga. Steel)
The Ultra Seam US-150CL 1.5-inch Clip-Loc panel is a high-performance standing seam metal roofing system designed for strength, longevity, and architectural appeal. It is available in 22-gauge and 24-gauge steel, Galvalume, aluminum, zinc, stainless steel, and copper. See the Roof Anchor Compatibility Chart for 22 Gauge and 24 Gauge US-150LS Lok-Seam Snaplock Ultra Seam Standing Seam Metal Roofing.
Fall Protection for US-150CL Panels
- For steel panels with 22-gauge and 24-gauge thickness: Use SSRA1 Seam Anchors, SSRA2 Adjustable Roof Jacks, and SSRA3 Anchor Plates. The SSRA1 clamps firmly to the standing seam ribs without penetrating the panel, providing a strong, OSHA-compliant tie-off point. When paired with SSRA2 Adjustable Roof Jacks, workers can install 10-foot-long wooden walkboards. Adding an SSRA3 Anchor Plate enables the setup of the 100-Foot SSRA Temporary HLL Kit. The SSRA1 is also compatible with the 120-Foot Super Anchor Permanent HLL Kit.
- For all other substrates: The Ridge Pro Steep Assist is the best fall protection option for steep-slope applications between 6:12 and 12:12. This system securely hooks over the roof peak, providing a stable tie-off point without drilling or clamping onto the seams.
US-100NS Nailstrip Panels (Ridge Pro Only)
Ultra Seam's US-100NS 1-inch Nailstrip panel is a standing seam metal roofing and siding system designed for residential and commercial applications. This panel offers a sleek and modern appearance while maintaining the structural durability required for high-performance roofing. See the Roof Anchor Compatibility Chart for Ultra SeamUS-100NS Nailstrip Standing Seam Metal Roofing.
Fall Protection for US-100NS Panels
When working on US-100NS panels, the Ridge Pro Steep Assist is the preferred fall protection solution for steep-slope applications between 6:12 and 12:12. This system securely hooks over the roof peak, providing a reliable tie-off point without requiring penetrations or clamps. The Ridge Pro ensures that workers remain 100% tied-off at all times.
US-100CS Batten Cap Panels (Ridge Pro Only)
The US-100CS 1-inch Batten Cap panel by Ultra Seam is a high-performance standing seam metal roofing system featuring a unique snap-on cap design. This panel is available in premium materials, including 22-gauge and 24-gauge steel, Galvalume, aluminum, zinc, stainless steel, and copper. See the Roof Anchor Compatibility Chart for Ultra Seam US-100CS Batten Cap Standing Seam Metal Roofing.
Fall Protection for US-100CS Panels
For roof slopes between 6:12 and 12:12, the Ridge Pro Steep Assist is the best option for fall protection. This system hooks securely over the roof peak, providing a stable and reliable tie-off point without requiring penetrations or direct seam attachment.
US-200-SB Mechanical Batten Panels (Ridge Pro Only)
The Ultra Seam US-200-SB Box Batten panel is a mechanically-seamed metal roofing system with a snap-on batten cap. It offers a distinctive architectural appearance and superior weather-tight performance. See the Roof Anchor Compatibility Chart for Ultra Seam US-200-SB Mechanical Batten Standing Seam Metal Roofing.
Fall Protection for US-200-SB Panels
For 6:12 to 12:12 pitch roofs, the Ridge Pro Steep Assist is the best fall protection option. This system hooks securely over the roof peak, providing a stable tie-off point without requiring penetrations. The Ridge Pro allows workers to maintain 100% tie-off, ensuring a safer work environment while navigating steep roof slopes.
Generic Imported Anchors vs. American-Made Reliability
Look, we all love a bargain. There is a certain thrill in finding a discount roof anchor for the price of a fast food combo meal. Cheap imports are great for novelty socks or tiny drink umbrellas, but they are slightly less ideal when they are the only thing standing between you and the pavement.
Bargain anchors often skip the testing and compliance hurdles necessary to keep your crew compliant and safe. That is why the SSRA system is designed, fabricated, and tested exclusively in the USA. We provide the comprehensive documentation required to satisfy OSHA 1926.502 and ANSI standards. When you buy an SSRA product, you get a compliant system that will not crumble under legal scrutiny and a dedicated American support staff ready to help with site-specific questions.
Standing Seam Roof Anchor Compatibility for 22 Gauge Ultra Seam Panels
| US-200 (22 Ga.) | US-175LS (22 Ga.) | US-150 (22 Ga.) | US-150LS (22 Ga.) | US-150CL (22 ga.) | |
|---|---|---|---|---|---|
SSRA 1 |
YES | YES | YES | YES | YES |
SSRA1 Nylon Tip |
YES | YES | YES | YES | YES |
SSRA2 Roof Jack |
YES | YES | YES | YES | YES |
SSRA3 Anchor Plate |
YES | YES | YES | YES | YES |
The Ridge Pro |
YES | YES | YES | YES | YES |
Standing Seam Roof Anchor Compatibility for 24 Gauge Ultra Seam Panels
| US-200 (24 Ga.) | US-175LS (24 Ga.) | US-150 (24 Ga.) | US-150LS (24 Ga.) | US-150CL (24 ga.) | |
|---|---|---|---|---|---|
| SSRA 1 |
NO | NO | NO | NO | NO |
| SSRA1 Nylon Tip |
YES | YES | YES | YES | YES |
| SSRA2 Roof Jack |
YES | YES | YES | YES | YES |
| SSRA3 Anchor Plate |
YES | YES | YES | YES | YES |
| The Ridge Pro |
YES | YES | YES | YES | YES |
Standing Seam Roof Anchor Compatibility for Ultra Seam Panels Cont.
| US-100NS Nailstrip | US-100CS Batten Cap | US-200-SB Mechanical Batten | |
|---|---|---|---|
| SSRA 1 |
NO | NO | NO |
| SSRA1 Nylon Tip |
NO | NO | NO |
| SSRA2 Roof Jack |
NO | NO | NO |
| SSRA3 Anchor Plate |
NO | NO | NO |
| The Ridge Pro |
YES | YES | YES |
Contact Us For More Information
For further details on roofing solutions and fall protection systems, contact us at 863-703-4522 or www.StandingSeamRoofAnchor.com. Let's work together to make your roofing projects safe, beautiful, and built to last. For more safety tips, check out OSHA's 48-page fall protection manual. Once you have determined the most suitable anchors for your roof system, download our free Anchor Inspection Form.
Safety Tips For Standing Seam Roofs
- Use Specialized Anchor Systems: Standard fastener-based anchors can compromise the roof's watertight integrity. Non-penetrating, seam-mounted anchors clamp securely to standing seams without drilling, providing dependable tie-off points for OSHA compliance.
- Develop OSHA-Compliant Safety Plans: A proactive safety plan should outline fall protection measures, emergency response protocols, and site-specific hazards.
- Install Permanent Roof Anchor Systems: Fixed tie-off points streamline safety procedures for buildings that require routine maintenance over several decades.
- Encourage the Use of Trauma Straps: Trauma straps allow workers to shift their weight and maintain blood flow while awaiting rescue, preventing suspension trauma.
- Set Up Protective Guardrail Barriers: Guardrails and warning lines create a safe perimeter and enhance hazard awareness, especially on large or low-slope roofs.
- Equip Workers with High-Quality Safety Gear: Workers should always use OSHA-compliant harnesses, lanyards, or self-retracting lifelines properly suited to their tasks.
- Ensure Proper Footwear for Stability: Metal roofs require slip-resistant boots with high-traction soles to provide grip, especially during wet or icy conditions.
- Prioritize Ladder Safety Training: Always place ladders on stable ground, secure them properly, and follow the 4-to-1 base-to-height rule.
- Consult Experts for Curved Metal Panels: Trained safety professionals can assess the job site and recommend the most appropriate tie-off methods for unique architectural profiles.
- Promote a Culture of Safety: Encouraging workers to report hazards and participate in regular training strengthens accountability and teamwork.
Disclaimer: The views, recommendations, and information presented in this blog are solely those of the author and do not necessarily reflect the opinions or positions of the featured panel manufacturer, its brands, subsidiaries, or parent companies. Customers are strongly encouraged to contact the roof panel manufacturer directly for inquiries about fall protection compatibility with their products and to address any potential warranty issues that may arise after installing our products.
