Ultra-Lok Assisted Rescue Pole/Tool for RSQ Self-Retracting Lifeline 6 - 12 ft
The DBI-SALA Ultra-Lok Assisted Rescue Pole 3500101 puts rescue within reach from a safe position. The telescoping pole extends from 6 to 12 feet and carries an RSQ assisted rescue tool head that engages the knob on an Ultra-Lok RSQ self-retracting lifeline, switching the unit from fall arrest mode to controlled descent so a suspended worker can be lowered without the rescuer climbing to them.
OSHA 1926.502 compliant. Part of the First-Man-Up and Ultra-Lok product series at 4.7 lb actual weight, light enough for one rescuer to deploy in seconds.
Who Needs This Product
Rescue teams and competent persons responsible for workers operating on Ultra-Lok RSQ dual-mode self-retracting lifelines. OSHA 1926.502(d)(20) requires prompt rescue of employees in the event of a fall; this pole is the assisted-rescue piece of that plan, letting a rescuer start a controlled descent from the deck, platform, or ground instead of climbing to the casualty.
Features
Telescoping 6 to 12 ft Reach
The pole adjusts across a 6 to 12 foot working range, covering suspended workers below leading edges, platforms, and cell tower work zones.
RSQ Assisted Rescue Tool Head
The included tool head seats on the engagement knob of an Ultra-Lok RSQ SRL and shifts the unit from fall arrest mode to descent mode.
Hands-Off Controlled Descent
Once engaged, the RSQ descent mechanism lowers the worker at a controlled rate. The rescuer never bears the load and never leaves a protected position.
One-Rescuer Operation
At 4.7 lb, one trained rescuer can carry, extend, and operate the pole without additional rigging or mechanical advantage systems.
First-Man-Up Series Compatibility
Built on the DBI-SALA First-Man-Up pole platform used to place and retrieve connectors at height, so crews can standardize on one pole system.
No Load Rating Required
The pole positions and activates equipment rather than carrying the worker, so there is no capacity limit to manage during the rescue.
Technical Specifications
| SKU | 3500101 |
|---|---|
| Connected Safety ID Equipped | No |
| For Use With | Ultra-Lok SRL |
| Overall Length | 6 ft |
| Product Series | First-Man-Up; Ultra-Lok |
| Product Type | Pole with RSQ Assisted Rescue Tool (For SRL) |
| Weight | 4.7 lb |
| Warranty | 3M Global Product Warranty against factory defects, one year from first use |
This pole is a rescue and positioning accessory, not a load-bearing device. Never use it to anchor, arrest, or suspend a load. The suspended worker remains supported by the Ultra-Lok RSQ SRL throughout the descent. Keep a documented rescue plan per OSHA 1926.502(d)(20).
Compliance Standards
OSHA 1926.502 and 1910.140
Meets OSHA personal fall protection requirements for construction and general industry.
3M Quality
Designed, tested, and certified by 3M Fall Protection, the successor to Capital Safety and the DBI-SALA legacy.
One-Year Warranty
Covered by the 3M Global Product Warranty against factory defects in workmanship and materials.
Typical Applications
Setup Overview
- Confirm the suspended worker is on an Ultra-Lok RSQ dual-mode SRL and the path below is clear for descent.
- Extend the pole to the reach required and lock the sections.
- Seat the RSQ assisted rescue tool head on the engagement knob of the SRL per the instruction manual.
- Engage the tool to switch the SRL from fall arrest mode to descent mode.
- Monitor the controlled descent until the worker reaches the landing zone, then provide care per your rescue plan.
Full use instructions ship with the unit; the instruction manual is linked in the documentation section below.
Inspection and Retirement
Inspect before each use, and have a competent person inspect the pole and tool head on a documented schedule per the 3M manual.
- Pole sections: extend smoothly, lock positively, and show no cracks, dents, or distortion.
- Tool head: no cracks, corrosion, deformation, or loose hardware at the RSQ interface.
- Locking mechanisms: engage fully and hold under hand pressure.
- Labels: present and legible, with the inspection log current.
Retirement triggers: any failed inspection, impact damage, or wear beyond the limits in the manual. 3M is the sole judge of warranty condition.
