FallTech Arc Flash Dorsal D-Ring Extender, 18 in
Provides improved over-the-shoulder reach for ease of connecting lanyards and SRLs. Constructed with Kevlar webbing and overmold insulated D-ring for arc flash hazard protection.
Choke-loop for harness attachment reduces electrical conductivity. Extender use will increase the user's total fall clearance distance when using an energy absorbing lanyard.
Who Needs This Product
A dorsal D-ring extender moves the connection point from between your shoulder blades to over your shoulder, where you can actually reach it. Crews connecting and disconnecting SRLs all day, and workers pairing with tie-back devices, run extenders so hookups are one-handed instead of a two-person job. EdgeCore versions carry leading-edge rated construction.
Features
Provides improved over-the-shoulder reach for
Provides improved over-the-shoulder reach for ease of connecting lanyards and SRLs.
Constructed
Constructed with Kevlar webbing and overmold insulated D-ring for arc flash hazard protection.
Choke-loop for harness attachment reduces
Choke-loop for harness attachment reduces electrical conductivity.
Extender use will increase the
Extender use will increase the user's total fall clearance distance when using an energy absorbing lanyard.
Complies
Complies with ANSI Z359.11-2014.
The extender adds to your fall distance. Add its length to the free fall side of your clearance calculation, and pair EdgeCore versions with leading-edge devices where sharp edges are in play.
Compliance Standards
ANSI Z359.11-2014
Applicable requirement for this equipment: ANSI Z359.11-2014.
OSHA 1926.502
Construction fall protection criteria for personal fall arrest system components, including connectors, lanyards, and lifelines.
Typical Applications
How to Use
Follow the FallTech instruction manual. The sequence below is an overview only.
- Install on the harness. The extender's loop or connector attaches at the dorsal D-ring per the manual.
- Route over the shoulder. The free end D-ring rides where you can see and reach it.
- Connect your device. SRL or lanyard clips to the extender D-ring.
- Count the length. Add the extender length to your fall clearance calculation.
Inspection and Retirement
Inspect with the harness before each use, and at least annually by a competent person.
- Webbing or cable: cuts, fraying, kinks.
- D-rings: no cracks, nicks, or corrosion.
- Stitching and terminations: intact.
Retirement triggers: any fall loading, webbing or hardware damage, or a failed inspection.
Fall ProtectionDistributors, LLC Free Tool · No Signup · OSHA 1926.502 Free Interactive Tool Fall Protection Calculator Pick your system. Run the math. Generate a plan. 1Pick Your SystemDetermine fall restraint vs. fall arrest based on your work surface, edge access, and clearance. 2Run the MathCalculate exact fall clearance required below the work surface for your lanyard or SRL setup. 3Generate a PlanGet a printable OSHA-compliant Fall Protection Plan structured around 29 CFR 1926.502(k).
Technical Specifications
| Type | 18" Kevlar Web |
|---|---|
| SKU | 8366LAF |
| Static Strength | 5,000 lb min. |
| OSHA User Capacity | 130 to 425 lb max. |
| Webbing | Kevlar; 5,000 lb min. static strength |
| D-ring | Overmolded alloy steel; 5,000 lb min. static strength |
| Choke-loop | Kevlar; 5,000 lb min. static strength |
| Standards | ANSI Z359.11-2014; OSHA 1926.502 and 1910.66; ASTM F887-20 |
| Warranty | FallTech 2-year limited warranty against defects in materials and workmanship |
