Super Anchor MAX X-Line Pneumatic Vertical Lifeline
The Super Anchor MAX X-Line is a pneumatic vertical lifeline that combines a rope lifeline with an integrated air line, so a worker on the roof can run pneumatic tools without a separate hose running back to the anchor. It is supplied with a snaphook end, without a rope grab, in 30 foot and 50 foot lengths.
Add the rope grab of your choice to complete the fall-arrest system. Choose your length at checkout.
Who Needs This Product
The X-Line is a vertical lifeline for roofers and trades running pneumatic nailers and tools at height who want the air supply integrated with the lifeline. Add a rope grab, a full-body harness, and a rated anchor to complete the system.
Features
Integrated air line
Runs pneumatic tool air along the lifeline, reducing separate hoses at height.
Two lengths
30 foot and 50 foot.
Snaphook end
Locking snaphook for the anchor connection.
No rope grab included
Add the rope grab of your choice for fall arrest.
Vertical lifeline
Provides a vertical rope lifeline for fall arrest.
ANSI Z359
Meets the American National Standard for vertical lifelines.
This is one component of a personal fall-arrest system. The X-Line ships without a rope grab; add a compatible rope grab before use for fall arrest. Inspect before each use and confirm compatibility, capacity, and fall clearance. Run the Fall Protection Calculator below before you tie off.
Compliance Standards
ANSI Z359
American National Standards for connecting components and energy absorbers.
OSHA 29 CFR 1926.502
Federal construction fall protection requirements.
Typical Applications
How to Use the MAX X-Line Pneumatic Lifeline
Follow the Super Anchor Safety instruction manual. The sequence below is an overview only.
- Inspect. Check for wear, cuts, distortion, corrosion, and gate or hardware function before each use.
- Confirm compatibility. Verify the component, harness, and anchor are compatible and rated.
- Connect. Make the connection and confirm every gate is fully closed and locked.
- Verify. Confirm the full system, capacity, and fall clearance.
- Use. Work within the rated limits of the system.
Inspection and Retirement
Inspect before each use, with a documented competent-person inspection at least annually. Remove the product from service for any condition below.
- Webbing or body: cuts, frays, abrasion, burns, corrosion, or distortion.
- Stitching: pulled, cut, or broken threads.
- Gates and locks: proper close and lock function.
- Fall indicators: any sign of deployment.
- Labels: illegible or missing markings.
Retire the anchor immediately after any fall-arrest event, or if any inspection point fails.
Fall ProtectionDistributors, LLC Free Tool · No Signup · OSHA 1926.502 Free Interactive Tool Fall Protection Calculator Pick your system. Run the math. Generate a plan. 1Pick Your SystemDetermine fall restraint vs. fall arrest based on your work surface, edge access, and clearance. 2Run the MathCalculate exact fall clearance required below the work surface for your setup. 3Generate a PlanGet a printable OSHA-compliant Fall Protection Plan structured around 29 CFR 1926.502(k).
Technical Specifications
| SKU | 4072 (30 ft), 4073 (50 ft) |
|---|---|
| Type | Pneumatic vertical lifeline |
| Air line | Integrated pneumatic tool air line |
| Lengths | 30 ft, 50 ft |
| Rope grab | Not included; add separately |
| End | Locking snaphook |
| Standards | ANSI Z359; OSHA 1926.502 |
| Warranty | Super Anchor Safety manufacturer warranty; see Warranty tab |
Frequently Asked Questions
Super Anchor MAX X-Line Pneumatic Lifeline Submittals and Documentation
Super Anchor Lifeline Instruction Manual 2024 (PDF)Vertical lifeline and rope grab use and inspection. Reverse Rigging Guide (PDF)Reverse rigging setup for vertical lifelines. Super Anchor Warranty and Compliance Statement (PDF)Manufacturer warranty and standards compliance.Related Super Anchor Products
Specifying Pneumatic Lifelines?
Length, rope grab, and air-tool needs all affect the setup. Confirm your application with us and we will help match the right X-Line configuration.
Call 863-703-4522 to talk to a fall protection specialist.
Super Anchor Safety Manufacturer Warranty
Super Anchor Safety (SAS) warrants to the purchaser that all products are free from defect in material and workmanship at the time of shipment. This warranty is limited to product replacement for a period of one (1) year from the date of installation or use by the owner, provided that this period shall not exceed two (2) years from the date of shipment. This warranty only covers defects in material and workmanship. It does not cover conditions resulting from normal wear, neglect, abuse, or accident. This product warranty does not cover oxidation of zinc, dacromet, or powder coatings used on permanent and temporary anchors that results from connector abrasion unless the coating can be shown to be defective at the time of purchase. This warranty is non-transferable. Any unused defective product will be replaced at no charge by returning the product to Super Anchor Safety or to the distributor the product was purchased from.
Permanent Anchor Warranty
Super Anchor Safety warrants to the purchaser that all anchors sold as a permanent fixture with Hot Dip Galvanizing, Stainless Steel, and Thermo-Plastic finishes are fully warranted against failure due to defects in materials or workmanship for a period of five (5) years from the date of initial installation. SAS does not warranty the installation or flashing system used to waterproof the anchors. The SAS factory warranty is void if the product has been modified or has not been used in accordance with SAS specifications and instructions for that product. Anchors that have been removed from service due to re-roofing or remodel of the structure they were originally attached to must be inspected by an SAS factory representative or a competent person before being reinstalled.
See the Super Anchor Warranty and Compliance Statement (PDF) for the full manufacturer document.
