Nano-Lok Personal Self-Retracting Lifeline with Anchor Hook, Web Aluminum Carabiner, 6 ft., Class 1, ANSI
Whether the application requires single or twin leg configurations, mounting to an overhead anchor, or connection directly to a harness, there are numerous fall protection models to choose from to suit almost any application. 3M DBI-SALA Nano-Lok Self-Retracting Lifeline (SRL) with Anchor Hook's smart activating brake system achieves fall clearance as low as 4 feet (1.2 m) while stopping a fall within inches and providing more protection at low heights. In addition, tension is always kept on the lifeline helping to reduce dragging, snapping, and trip falls.
ANSI Class Level 1; ANSI/ASSP Z359.14-2021; 29 CFR OSHA 1910.140; 29 CFR OSHA 1926.502 The quick-activating speed sensing brake arrests a fall within inches, and constant lifeline tension eliminates the dragging and snag hazards of a lanyard.
Who Needs This Product
This configuration suits crews that anchor overhead and want the shortest possible arrest with the least equipment on the worker. Match the top connector to your anchor hardware and the lifeline hook to the harness dorsal D-ring.
Features
Swiveling anchorage loop with carabiner
Swiveling anchorage loop with carabiner, engineered into this DBI-SALA configuration as standard.
Quick activating speed sensing brake
Quick activating speed sensing brake system, engineered into this DBI-SALA configuration as standard.
Self-locking snap hook on lifeline
Self-locking snap hook on lifeline, engineered into this DBI-SALA configuration as standard.
Compact & lightweight design
Compact & lightweight design, engineered into this DBI-SALA configuration as standard.
Durable thermoplastic housing
Durable thermoplastic housing, engineered into this DBI-SALA configuration as standard.
High capacity external energy absorber
High capacity external energy absorber and impact indicator.
Technical Specifications
| SKU | 3100528 |
|---|---|
| Anchor Connection Type | Carabiner |
| Anchor Hook Material | Aluminum |
| Average Arrest Force | 1125 lbf (ANSI); 1125 lbf (OSHA 130 lb - 310 lb) |
| Connected Safety ID Equipped | Yes |
| Housing Material | Nylon Thermoplastic |
| Install Type | Portable & Removable |
| Leg Count | Single-Leg |
| Lifeline Connection Type | Carabiner |
| Lifeline Hook Material | Aluminum |
| Lifeline Length | 6 ft |
| Lifeline Material | Web |
| Maximum Arrest Force | 1800 lbf (ANSI); 1800 lbf (OSHA 130 lb - 310 lb) |
| Maximum Number of Users | One |
| Mounting Type | Overhead Anchor Point |
| Net Weight | 2.134 lb |
| Overall Length | 6 ft |
| Product Series | Nano-Lok |
| Product Type | Self Retracting Lifeline with Anchor Hook - Web |
| Specifications Met | ANSI Class Level 1; ANSI/ASSP Z359.14-2021; 29 CFR OSHA 1910.140; 29 CFR OSHA 1926.502 |
Anchor at or above the D-ring. This is a Class 1 device: free fall is limited to 2 ft, and it is not rated for foot-level tie-off or leading edge exposure. Remove the unit from service immediately after any fall arrest.
Compliance Standards
ANSI/ASSP Z359.14-2021 Class 1
Certified as a Class 1 self-retracting device under the 2021 standard that replaced the legacy Class A and B designations.
OSHA 1926.502 and 1910.140
Meets OSHA personal fall protection requirements for construction and general industry.
3M Quality
Designed, tested, and certified by 3M Fall Protection, the successor to Capital Safety and the DBI-SALA legacy.
One-Year Warranty
Covered by the 3M Global Product Warranty against factory defects in workmanship and materials.
Typical Applications
Setup Overview
- Inspect the housing, lifeline, energy absorber and impact indicator, and both connectors before use.
- Connect the top connector to the overhead anchorage or anchorage connector and verify the gate closes and locks.
- Connect the lifeline hook to the harness dorsal D-ring and verify the gate closes and locks.
- Check retraction: the lifeline should pay out and retract smoothly with constant tension.
- Verify anchor position and fall clearance per the manual clearance tables before working.
Full use instructions ship with the unit; the instruction manual is linked in the documentation section below.
Inspection and Retirement
Inspect before each use, and have a competent person inspect the unit on a documented schedule per the applicable ANSI standard and the 3M manual.
- Hardware: cracks, distortion, corrosion, and loose fasteners.
- Webbing or lifeline: cuts, frays, burns, abrasion, and chemical damage.
- Connectors: gates close and lock; no distortion at either end.
- Labels: present and legible, with the inspection log current.
- Retraction and brake: smooth payout, positive lock on a sharp pull, and an undeployed impact indicator.
Retirement triggers: any fall arrest event, failed inspection, or damage beyond the limits in the manual.
