FallTech 744850 Concrete Embed D-Ring Anchor (4 ft, 50-Pack)
The FallTech 744850 is a bulk 50-pack of 4-foot concrete embed d-ring anchors. Each strap is cast into fresh concrete to create a permanent, single-use tie-off point, and the 50-count case pack is sized for large pours where crews set many anchors at once.
Each anchor meets ANSI Z359.1-2007 and ANSI A10.32-2004, rated to a 5,000 lb anchorage requirement for one worker up to 310 lb. This is the economical way to stock 4-foot embed d-ring anchors for a big job.
Who Needs This Product
This product is a 50-count bulk pack of 4-foot concrete embed d-ring anchors for large concrete pours. Concrete and precast crews cast each strap into the wet slab so a tie-off point is available once cured. Each is a single-use, permanent anchor. You still need a certified full-body harness and a compatible connecting device, and the anchors must not be used to lift or support loads.
Features
Bulk 50-count pack
Stock 4-foot embed anchors economically for a large pour.
Cast into concrete
Each strap becomes a permanent part of the slab or wall.
D-Ring connection
Finished with a forged steel D-ring at the surface.
Polyester web strap
Strong embedded webbing that bonds into the cured concrete.
ANSI Z359.1-2007 and A10.32
Each anchor meets or exceeds the applicable standards.
Job-lot quantity
One case covers a large layout of anchor points.
Cast-in anchors, single use only. Not for lifting. Embed each strap fully per the instruction manual in properly cured concrete, and never use an anchor to lift, hang, or support loads. Do not knot the webbing. Confirm fall clearance and swing-fall with the Fall Protection Calculator below.
Compliance Standards
ANSI Z359.1-2007
Fall protection component standard; each embed strap meets or exceeds it.
ANSI A10.32-2004
Construction fall protection standard for the embed anchor.
OSHA 1926.500-503
Federal construction fall protection requirements.
Single-use
Permanent cast-in anchors; not removable or reusable.
Typical Applications
How to Install Each Anchor
Follow the FallTech instruction manual. The sequence below is an overview only.
- Plan the layout. Mark anchor locations and confirm slab thickness and edge distance per the manual.
- Position before the pour. Secure each embed strap so the connection end sits at the finished surface.
- Cast in concrete. Pour and consolidate around each fully embedded strap.
- Cure fully. Let the concrete reach its required strength before use.
- Inspect and connect. Inspect each anchor, connect your SRL or lanyard, and confirm fall clearance below.
Inspection and Retirement
Inspect before each use, with a documented competent-person inspection at least annually. Remove the anchor from service for any of the conditions below.
- Connection point at the surface: cuts, fraying, or damage where it exits the concrete.
- Hardware or loop: deformation, sharp edges, corrosion, or worn stitching.
- Concrete around each anchor: cracking or spalling.
- Labels: illegible or missing markings.
Remove the anchor from service immediately after any fall-arrest event, and destroy retired equipment so it cannot return to service.
Fall ProtectionDistributors, LLC Free Tool · No Signup · OSHA 1926.502 Free Interactive Tool Fall Protection Calculator Pick your system. Run the math. Generate a plan. 1Pick Your SystemDetermine fall restraint vs. fall arrest based on your work surface, edge access, and clearance. 2Run the MathCalculate exact fall clearance required below the work surface for your lanyard or SRL setup. 3Generate a PlanGet a printable OSHA-compliant Fall Protection Plan structured around 29 CFR 1926.502(k).
Technical Specifications
| Type | Bulk 50-pack, 4 ft concrete embed d-ring anchor (cast-in) |
|---|---|
| Quantity | 50 anchors per case |
| Material | Polyester web strap with forged steel D-ring |
| Embed length | 4 ft |
| Anchorage requirement | 5,000 lb |
| Capacity | One worker, 130 to 310 lb combined |
| Use | Single-use, permanent cast-in anchors |
| Standards | ANSI Z359.1-2007; ANSI A10.32-2004; OSHA 1926.500-503 |
| Warranty | FallTech 2-year limited warranty against defects in materials and workmanship |
Frequently Asked Questions
FallTech 744850 Submittals and Documentation
744850 Instruction Manual (PDF)Installation, capacity, and inspection. 744850 Declaration of Conformity (PDF)Certification to ANSI Z359.1-2007 and A10.32-2004 (FallTech test lab). 744850 Spec Sheet (PDF)One-page specifications summary.Related Anchors
- FallTech steel and beam anchors. See the full beam clamp and steel anchor line.
- FallTech fall protection equipment. Harnesses, SRLs, lanyards, and anchors.
Stocking Embed Anchors for a Big Pour?
Large pours need anchors staged before concrete day. Confirm your layout and counts with us and we will get the right cases to the site on schedule.
Call 863-703-4522 to talk to a fall protection specialist.
