MPS Cross Arm Strap with Reinforced Webbing
The Frontline MPS cross arm strap turns a beam, truss, or other structural member into an anchorage point in seconds. Wrap the strap around the member, pass the small D-ring through the large D-ring, and connect your fall protection system to the large ring - a classic choker-style cross arm anchor.
The strap is sewn from 1.73 in polyester webbing with a 2.5 in reinforcing layer stitched to the back for extra abrasion protection, and finished with golden yellow galvanized alloy steel D-rings. Webbing and connectors each carry a 5,000 lb breaking strength with a 310 lb max capacity. Per the Frontline spec sheet it conforms to ANSI Z359.18-2017 Type T and ANSI A10.32-2004 and aligns with OSHA 1926 and 1910. Lengths run from 3 ft to 30 ft.
Product Video
See the Frontline multifunction anchors used as versatile tie-off points across roof and structural applications.
Who Needs This Product
This product is a wrap-around anchorage connector for personal fall arrest or restraint systems. Steel erectors, mechanical crews, scaffolders, and maintenance teams use cross arm straps to anchor to overhead beams, joists, and trusses without drilling or welding. Each worker still needs a full body harness and a compatible connecting device attached to the large D-ring.
Features
Choker-style connection
Pass the small D-ring through the large one and the strap cinches tight to the member.
Reinforced webbing back
A 2.5 in webbing layer stitched over the 1.73 in primary strap shields it from edge abrasion.
High-tenacity stitching
Sewn with high-tenacity polyester thread for full anchorage-grade strength.
Anchorage-grade hardware
Alloy steel D-rings in golden yellow galvanized finish, rated to 5,000 lbs.
Six lengths
3, 4, 6, 12, 20, and 30 ft cover columns, beams, and large structural members.
No tools required
Wrap, choke, connect - and remove it just as fast when the task is done.
Technical Specifications
| SKU | MPS |
|---|---|
| Type | Cross arm strap / web anchorage sling (choker configuration) |
| Webbing | Polyester, 1.73 in inner width with 2.5 in reinforcing outer layer |
| Stitching | High-tenacity polyester thread |
| Hardware | Alloy steel D-rings, golden yellow galvanized finish |
| Webbing breaking strength | 5,000 lbs |
| Connector breaking strength | 5,000 lbs |
| Max capacity | 310 lbs (one worker) |
| Lengths | 3 ft, 4 ft, 6 ft, 12 ft, 20 ft, 30 ft |
| Standards | ANSI Z359.18-2017 Type T; ANSI A10.32-2004; OSHA 1926; OSHA 1910 |
Mind the edges. Wrap the strap so the reinforced layer rides against the structure and keep the webbing clear of sharp or hot edges. The structure you choke must itself support anchorage loads - have a qualified person verify the member before anyone ties off. One worker per strap at 310 lbs maximum.
Compliance Standards
ANSI Z359.18-2017 Type T
American National Standard for anchorage connectors; Type T covers single-point anchorage connectors of this class. Third-party tested by INSPEC - see the test report in Submittals.
ANSI A10.32-2004
Fall protection requirements for construction and demolition operations.
OSHA 29 CFR 1926.502
Federal construction fall protection criteria, including anchorage strength requirements.
OSHA 29 CFR 1910.140
General industry personal fall protection system requirements.
Typical Applications
How to Rig the MPS Cross Arm Strap
Follow the manufacturer's manual. The sequence below is an overview only.
- Select the member. Have a qualified person confirm the beam or truss can support anchorage loads.
- Inspect the strap. Check webbing, stitching, and both D-rings before each use.
- Wrap the member. Pass the strap around the structural member with the reinforced layer against the steel.
- Choke it. Pass the small D-ring through the large D-ring and pull snug.
- Connect. Attach your connecting device to the large D-ring only, then perform a pull test.
- Verify clearance. Confirm fall clearance below the work surface before work begins.
Inspection and Retirement
Inspect before each use, with a documented competent-person inspection at least every 6 months. Pull the equipment from service for any of the conditions below.
- Webbing: cuts, fraying, abrasion, burns, or chemical damage on either layer.
- Stitching: broken, pulled, or abraded threads at the sewn terminations.
- D-rings: deformation, cracks, corrosion, or sharp edges.
- UV degradation: fading, stiffness, or surface chalking from sun exposure.
- Markings: labels must be present and legible.
Retire the strap immediately after any fall arrest event or if any inspection point fails. Destroy retired equipment so it cannot return to service.
