Name: Super Anchor Hold-Me Rope Termination Anchor Plate
Brand: Super Anchor
SKU: 1036
Price: 148.8 USD
Availability: InStock

Description
Warranty Information
Reviews

Super Anchor Temporary Anchors

Super Anchor Hold-Me Rope Termination Temporary Anchor Plate

The Super Anchor Hold-Me is a rope termination anchor plate that connects a rope to structure without knots or factory terminations. It provides an effective way to make compliant end terminations in the field, and it works with all Super Anchor 5/8 inch vertical lifelines.

The Hold-Me plate is 2 inches wide and 10 inches tall with six holes, is constructed from 6061-T6 aluminum, and weighs just 9.3 ounces. It carries a 5,000 pound ultimate load capacity and complies with ANSI Z359.1. Because knots reduce rope strength, the plate lets you terminate without them.

Super Anchor Hold-Me rope termination anchor plate, 6061-T6 aluminum, for 5/8 inch lifelines

5,000 lbUltimate Load

310 lbMax User Weight

6061-T6Aluminum

9.3 ozWeight

2 x 10 inPlate Size

6 HolesTermination Points

5/8 inLifeline Rope

ANSI Z359.1Compliant

Who Needs This Product

The Hold-Me is a temporary anchor plate for workers who need to terminate a 5/8 inch vertical lifeline in the field without tying knots. It suits rope access and lifeline setups where a clean, compliant end termination matters. Complete the system with a full-body harness, a rope grab, and a compatible lifeline.

Features

No knots required

Terminates a rope to structure without knots or factory terminations.

Field terminations

An effective way to make compliant end terminations on the jobsite.

Fits 5/8 inch lifelines

Works with all Super Anchor 5/8 inch vertical lifelines.

6061-T6 aluminum

Lightweight aluminum plate that weighs just 9.3 ounces.

Six termination holes

A 2 by 10 inch plate with six holes for the rope termination.

5,000 lb ultimate load

Rated to a 5,000 lb ultimate load capacity and compliant with ANSI Z359.1.

⚠

This is a rope termination anchor, not a complete system. Knots shall not be used for termination because they reduce rope strength. Attach to structure capable of the load, use a full-body harness with a rated lifeline and rope grab, and confirm fall clearance. Run the Fall Protection Calculator below before you tie off.

Compliance Standards

ANSI Z359.1

American National Standard for fall arrest components, section 3.2.7.2.2.

OSHA 29 CFR 1926.502

Federal construction fall protection anchorage requirements.

Typical Applications

Rope accessClean field terminations for vertical lifelines.

Lifeline riggingTerminate 5/8 inch rope without knots.

RoofingRope tie-off with a compliant end termination.

MaintenanceReusable rope termination for service work.

How to Use the Hold-Me Anchor

Follow the Super Anchor Safety instruction manual. The sequence below is an overview only.

Confirm the structure. Verify the attachment point is capable of the load per a competent person.
Route the rope. Thread the 5/8 inch lifeline rope through the plate holes per the instruction manual.
Terminate. Make the compliant termination without knots as shown in the manual.
Connect. Attach your rope grab and harness to the lifeline.
Verify. Confirm the termination is correct and confirm fall clearance before use.

Inspection and Retirement

Inspect before each use, with a documented competent-person inspection at least annually. Remove the product from service for any condition below.

Plate: cracks, deformation, corrosion, or elongated holes.
Rope termination: correct routing, no slippage, no knots.
Edges: burrs or sharp edges that could damage the rope.
Labels: illegible or missing product identification.

Retire the anchor immediately after any fall-arrest event, or if any inspection point fails.

Fall Protection
Distributors, LLC Free Tool · No Signup · OSHA 1926.502 Free Interactive Tool Fall Protection Calculator Pick your system. Run the math. Generate a plan. 1Pick Your SystemDetermine fall restraint vs. fall arrest based on your work surface, edge access, and clearance. 2Run the MathCalculate exact fall clearance required below the work surface for your setup. 3Generate a PlanGet a printable OSHA-compliant Fall Protection Plan structured around 29 CFR 1926.502(k). Run the Numbers and Stay Safe Launch the Calculator ›

Technical Specifications

SKU	1036
Manufacturer Part Number	1036
Type	Rope termination anchor plate
Material	6061-T6 aluminum
Size	2 in wide by 10 in tall, six holes
Weight	9.3 oz
Ultimate load	5,000 lb
Max user weight	310 lb
Compatible rope	5/8 in vertical lifelines
Standards	ANSI Z359.1 section 3.2.7.2.2
Warranty	Super Anchor Safety manufacturer warranty; see Warranty tab

Frequently Asked Questions

What does the Hold-Me do?

It terminates a rope to structure without knots or factory terminations, making a compliant field end termination. Following the manufacturer guidance on this page is part of keeping your equipment audit ready. A qualified person should verify that the installation and the overall system meet the requirements of your specific job site.

What rope does it fit?

All Super Anchor 5/8 inch vertical lifelines. Confirm each component in the system is compatible and rated for the intended use before connecting to it. If you have any doubt about the correct setup, consult a qualified person or the manufacturer instructions before putting the system into service.

Why avoid knots?

Knots reduce rope strength. The Hold-Me lets you terminate without them for a stronger, compliant connection. Make sure the connecting hardware and anchorage suit your application before you attach a lanyard or lifeline. Store it in a clean, dry place away from heat and chemicals to help preserve its condition between uses.

What is it made of?

6061-T6 aluminum. The plate is 2 by 10 inches with six holes and weighs 9.3 ounces. Refer to the specification table above for full details on construction, finish, and sizing. If you have any doubt about the correct setup, consult a qualified person or the manufacturer instructions before putting the system into service.

What is the load rating?

A 5,000 pound ultimate load capacity, compliant with ANSI Z359.1. The specifications listed on this page outline the build details you need for your application. If you have any doubt about the correct setup, consult a qualified person or the manufacturer instructions before putting the system into service.

What is the maximum user weight?

310 pounds, per the Hold-Me specification sheet. See the Technical Specifications on this page for the exact materials, dimensions, and ratings. Always inspect the product before each use and take it out of service if you notice any damage, deformation, or excessive wear. Before every use, confirm the product is compatible with the rest of your fall protection system and that you have adequate fall clearance below the work area.

Do I need a harness with this anchor?

Yes. The plate is a rope termination point only and must be paired with a rated lifeline, rope grab, and full-body harness. Make sure the connecting hardware and anchorage suit your application before you attach a lanyard or lifeline. Keep the manufacturer instructions with the equipment so anyone using it can reference the approved procedures.

Super Anchor Hold-Me Rope Termination Anchor Submittals and Documentation

Hold-Me Spec Sheet (PDF)Specifications and compliance summary. Hold-Me Termination Manual (PDF)Rope termination instructions and inspection. End Termination Plate Spec (PDF)End termination plate specification. Warranty and Compliance Statement (PDF)Manufacturer warranty and standards compliance.

Related Super Anchor Products

Terminating Lifelines in the Field?

Rope size, structure, and rope grab compatibility all affect a compliant termination. Confirm your lifeline setup with us and we will help match the Hold-Me with the right rope and PPE.

Call 863-703-4522 to talk to a fall protection specialist.

Super Anchor Safety Manufacturer Warranty

Super Anchor Safety (SAS) warrants to the purchaser that all products are free from defect in material and workmanship at the time of shipment. This warranty is limited to product replacement for a period of one (1) year from the date of installation or use by the owner, provided that this period shall not exceed two (2) years from the date of shipment. This warranty only covers defects in material and workmanship. It does not cover conditions resulting from normal wear, neglect, abuse, or accident. This product warranty does not cover oxidation of zinc, dacromet, or powder coatings used on permanent and temporary anchors that results from connector abrasion unless the coating can be shown to be defective at the time of purchase. This warranty is non-transferable. Any unused defective product will be replaced at no charge by returning the product to Super Anchor Safety or to the distributor the product was purchased from.

Permanent Anchor Warranty

Super Anchor Safety warrants to the purchaser that all anchors sold as a permanent fixture with Hot Dip Galvanizing, Stainless Steel, and Thermo-Plastic finishes are fully warranted against failure due to defects in materials or workmanship for a period of five (5) years from the date of initial installation. SAS does not warranty the installation or flashing system used to waterproof the anchors. The SAS factory warranty is void if the product has been modified or has not been used in accordance with SAS specifications and instructions for that product. Anchors that have been removed from service due to re-roofing or remodel of the structure they were originally attached to must be inspected by an SAS factory representative or a competent person before being reinstalled.

See the Super Anchor Warranty and Compliance Statement (PDF) for the full manufacturer document.
