Super Anchor Ultra-Viz Full Body Harness, No Bags, 6160
The Super Anchor 6160 Ultra-Viz is a high-visibility full body harness built with ANSI Class 1 fluorescent green reflective material for maximum worker visibility. It provides a dorsal fall-arrest D-ring and a comfortable, padded deluxe frame without tool bags.
The 6160 is offered in Medium through X-Large including a Long-Large size and is certified to ANSI Z359.11 for fall arrest.
Who Needs This Product
The 6160 Ultra-Viz is a high-visibility harness for road, utility, and site work where worker visibility matters. Its ANSI Class 1 reflective material stands out day and night. Complete the system with an energy-absorbing lanyard or SRL and a rated anchor.
Features
ANSI Class 1 hi-vis
Fluorescent green reflective material for maximum visibility.
Deluxe padded frame
Padded harness frame for all-day comfort.
Dorsal fall-arrest D-ring
Rear D-ring for personal fall arrest.
Long-Large option
Includes a Long-Large size for taller workers.
No bags
Clean deluxe configuration without tool bags.
ANSI Z359.11
Meets the American National Standard for full body harnesses.
A harness is one part of a personal fall-arrest system. High visibility material supports, but does not replace, required high-visibility apparel. Inspect before each use, use a compatible energy-absorbing lanyard or self-retracting lifeline and a rated anchor, and confirm fall clearance. Run the Fall Protection Calculator below before you tie off.
Compliance Standards
ANSI Z359.11
American National Standard for full-body harnesses.
OSHA 29 CFR 1926.502
Federal construction fall protection requirements.
Typical Applications
How to Use Ultra-Viz Harness
Follow the Super Anchor Safety instruction manual. The sequence below is an overview only.
- Inspect. Check all webbing, stitching, hardware, and fall indicators before each use.
- Don the harness. Step in, pull it up, and connect the chest and leg buckles.
- Adjust the fit. Snug all straps so the dorsal D-ring sits between the shoulder blades.
- Connect. Attach your energy-absorbing lanyard or self-retracting lifeline to the dorsal D-ring.
- Verify clearance. Confirm anchorage, connectors, and fall clearance before working at height.
Inspection and Retirement
Inspect before each use, with a documented competent-person inspection at least annually. Remove the product from service for any condition below.
- Webbing: cuts, frays, abrasion, burns, chemical damage, or heat glazing.
- Stitching: pulled, cut, or broken threads.
- Hardware: D-rings, buckles, and keepers for distortion, cracks, corrosion, or sharp edges.
- Fall indicators: any sign of deployment or activation.
- Labels: illegible or missing markings.
Retire the anchor immediately after any fall-arrest event, or if any inspection point fails.
Fall ProtectionDistributors, LLC Free Tool · No Signup · OSHA 1926.502 Free Interactive Tool Fall Protection Calculator Pick your system. Run the math. Generate a plan. 1Pick Your SystemDetermine fall restraint vs. fall arrest based on your work surface, edge access, and clearance. 2Run the MathCalculate exact fall clearance required below the work surface for your setup. 3Generate a PlanGet a printable OSHA-compliant Fall Protection Plan structured around 29 CFR 1926.502(k).
Technical Specifications
| SKU | 6160-M/L/LL/X |
|---|---|
| Manufacturer Part Number | 6160 series |
| Type | Ultra-Viz deluxe full body harness, no bags |
| Material | ANSI Class 1 fluorescent green reflective |
| Dorsal D-ring | Rear fall-arrest D-ring |
| Capacity | 310 lb |
| Sizes | Medium, Large, Long-Large, X-Large |
| Standards | ANSI Z359.11; OSHA 1926.502 |
| Warranty | Super Anchor Safety manufacturer warranty; see Warranty tab |
Frequently Asked Questions
Ultra-Viz Harness Submittals and Documentation
Super Anchor Deluxe Harness Manual (PDF)Use, fitting, capacity, and inspection.Super Anchor Warranty and Compliance Statement (PDF)Manufacturer warranty and standards compliance.Related Super Anchor Products
Need High-Visibility Harnesses?
Visibility class and worker size affect the right harness. Confirm your site requirements with us and we will help match the right Ultra-Viz harness and connectors.
Call 863-703-4522 to talk to a fall protection specialist.
Super Anchor Safety Manufacturer Warranty
Super Anchor Safety (SAS) warrants to the purchaser that all products are free from defect in material and workmanship at the time of shipment. This warranty is limited to product replacement for a period of one (1) year from the date of installation or use by the owner, provided that this period shall not exceed two (2) years from the date of shipment. This warranty only covers defects in material and workmanship. It does not cover conditions resulting from normal wear, neglect, abuse, or accident. This product warranty does not cover oxidation of zinc, dacromet, or powder coatings used on permanent and temporary anchors that results from connector abrasion unless the coating can be shown to be defective at the time of purchase. This warranty is non-transferable. Any unused defective product will be replaced at no charge by returning the product to Super Anchor Safety or to the distributor the product was purchased from.
Permanent Anchor Warranty
Super Anchor Safety warrants to the purchaser that all anchors sold as a permanent fixture with Hot Dip Galvanizing, Stainless Steel, and Thermo-Plastic finishes are fully warranted against failure due to defects in materials or workmanship for a period of five (5) years from the date of initial installation. SAS does not warranty the installation or flashing system used to waterproof the anchors. The SAS factory warranty is void if the product has been modified or has not been used in accordance with SAS specifications and instructions for that product. Anchors that have been removed from service due to re-roofing or remodel of the structure they were originally attached to must be inspected by an SAS factory representative or a competent person before being reinstalled.
See the Super Anchor Warranty and Compliance Statement (PDF) for the full manufacturer document.
