QAN75RA-US Patriot Confined Space Quadpod with 3-Way Retrieval, Made in USA
The Frontline QAN75RA-US is a Patriot confined space quadpod - a four-legged retrieval frame for openings where a tripod's three legs will not straddle the hole. Ideal where the use of a tripod is impractical, it sets up in seconds with no tools and can be erected by one person.
Made in the USA, it carries a 3-way retrieval SRL that arrests a fall and lets the attendant raise or lower the worker for non-entry rescue. The four-leg stance spans wider, rectangular, and off-center openings that defeat a tripod. Built to OSHA 1910.146 and ANSI Z359.
Who Needs This Product
This product is a confined space quadpod retrieval system for openings a tripod cannot span. Confined space teams use it for entry support and non-entry rescue. It requires a full body harness and a written, practiced rescue plan to form a complete program.
Features
Reaches openings a tripod cannot
The four legs straddle wide, rectangular, and off-center holes where a three-leg frame has nowhere to stand.
Rescue without entry
The retrieval block lifts or lowers a fallen worker so the attendant never has to climb in after them.
Steady lifting point
The wide stance keeps the overhead retrieval point stable through a full raise or lower.
Matched and ready
It ships with the 3-way retrieval SRL, so the frame and the rescue block arrive as one kit.
Fits tanks, vaults, and pits
Sized for the large and irregular permit-space openings that a tripod cannot cover.
Moves with the crew
It sets up and breaks down by hand, so one team can carry it between openings across a site.
Technical Specifications
| SKU | QAN75RA-US |
|---|---|
| Type | Confined space quadpod with 3-way retrieval, Made in USA |
| Stance | Four legs - spans openings a tripod cannot |
| Setup | Seconds, no tools, one person |
| Retrieval | 3-way SRL: fall arrest + raise/lower |
| Country of manufacture | USA |
| Standards | OSHA 1910.146; ANSI Z359; OSHA 1926 |
Confined space demands a rescue plan. This equipment is part of an entry and non-entry rescue system, not a substitute for the written, practiced rescue plan OSHA 1910.146 requires. Verify every anchorage, base, and connection per the Frontline manual before any entry, and train your team first.
Compliance Standards
OSHA 29 CFR 1910.146
Permit-required confined spaces: entry, attendant, and rescue requirements.
ANSI Z359
Fall protection and rescue system standards for the system and its components.
OSHA 29 CFR 1926
Construction confined space and fall protection requirements.
Typical Applications
How to Use the QAN75RA-US
Follow the manufacturer's manual. The sequence below is an overview only.
- Inspect. Check all load-bearing parts, moving parts, and the line before each use.
- Set up per the manual. Install and rig exactly as the Frontline manual specifies.
- Rig the system. Run the retrieval and/or fall arrest lines through the correct points.
- Connect the worker. Attach the harness per the rescue plan.
- Function-test. Test retrieval and confirm the plan with the attendant before entry.
Inspection and Retirement
Inspect before each use, with a documented competent-person inspection at least every 6 months. Pull the equipment from service for any of the conditions below.
- Visual: deformation, cracks, corrosion, or damaged welds on load-bearing parts.
- Moving parts: pulleys, swivels, winch drum, and locks operate freely and lock positively.
- Line/cable: no broken wires, kinks, fraying, or corrosion; spools cleanly.
- Connectors and fasteners: present, correct, and fully engaged per the manual.
- Labels and markings: present and legible.
Retire the equipment immediately after any fall arrest event or if any inspection point fails. Destroy retired equipment so it cannot return to service.
