FallTech Cable Pass-Through Sling Anchor with Vinyl-Coated Steel Cable
The FallTech Cable Pass-Through Sling Anchor with vinyl-coated cable is a galvanized steel wire-rope anchor with a protective vinyl coating. It wraps a rated structure and cinches on, resisting cuts and abrasion while the coating helps protect finished surfaces and the cable itself.
It is built from vinyl-coated galvanized steel wire rope with a pass-through thimble, rated for 5,000 lb (22.2 kN) and certified to ANSI Z359.18-2017. Choose from lengths of 4', 6', 8', 10', 12' to fit the member.
Who Needs This Product
This product is a vinyl-coated cable pass-through sling anchor, the anchorage component of a personal fall arrest system. Crews who need cable strength but want to protect finished surfaces wrap it around a rated member and cinch it on, then connect an SRL or lanyard. You still need a certified full-body harness and a compatible connecting device to complete the system.
Features
Vinyl-coated cable
Protective coating shields finished surfaces and the wire rope.
Steel wire rope
Galvanized cable resists cuts and abrasion better than webbing.
Wraps any rated member
Girth-hitches around beams, columns, and structures without hardware.
Several lengths
Available from 4 ft to 12 ft to fit the member.
Reusable and portable
No tools needed; stows easily in a gear bag.
ANSI Z359.18-2017
Certified anchorage rated for 5,000 lb (22.2 kN).
Confirm the structure and protect against sharp edges. The coating protects surfaces but the cable is still not cut-proof. Confirm the anchor structure is rated for at least 5,000 lb and avoid sharp, jagged edges. Confirm fall clearance and swing-fall with the Fall Protection Calculator below.
Compliance Standards
ANSI Z359.18-2017
American National Standard for anchorage connectors. 5,000 lb (22.2 kN).
OSHA 29 CFR 1926.502
Federal construction fall protection anchorage requirements.
OSHA 29 CFR 1910
General industry personal fall protection requirements.
5,000 lb rated
Minimum breaking strength of 5,000 lb (22.2 kN).
Typical Applications
How to Install
Follow the FallTech instruction manual. The sequence below is an overview only.
- Inspect. Check the webbing, stitching, and hardware for damage before each use.
- Choose a rated anchor point. Confirm the structure supports at least 5,000 lb and is free of sharp or abrasive edges.
- Wrap the structure. Pass the anchor around the beam, column, or member in the approved configuration.
- Connect. Attach your SRL or energy-absorbing lanyard to the anchor connection point.
- Check clearance. Confirm fall clearance and swing-fall with the calculator below.
Inspection and Retirement
Inspect before each use, with a documented competent-person inspection at least annually. Remove the anchor from service for any of the conditions below.
- Wire rope: kinks, birdcaging, broken wires, corrosion, or crushing.
- Swages and thimbles: cracks, slippage, or deformation.
- Hardware (carabiner, hook, D-ring, or O-ring): deformation, corrosion, or a gate that will not lock.
- Coating (if present) and labels: heavy damage, or illegible markings.
Remove the anchor from service immediately after any fall-arrest event, and destroy retired equipment so it cannot return to service.
Fall ProtectionDistributors, LLC Free Tool · No Signup · OSHA 1926.502 Free Interactive Tool Fall Protection Calculator Pick your system. Run the math. Generate a plan. 1Pick Your SystemDetermine fall restraint vs. fall arrest based on your work surface, edge access, and clearance. 2Run the MathCalculate exact fall clearance required below the work surface for your lanyard or SRL setup. 3Generate a PlanGet a printable OSHA-compliant Fall Protection Plan structured around 29 CFR 1926.502(k).
Technical Specifications
| Type | Cable pass-through sling anchor, vinyl-coated |
|---|---|
| Material | Vinyl-coated galvanized steel wire rope with pass-through thimble |
| Anchorage classification | ANSI Z359.18-2017 |
| Minimum breaking strength | 5,000 lb (22.2 kN) |
| Capacity (ANSI) | One worker, up to 310 lb combined |
| Lengths available | 4', 6', 8', 10', 12' |
| Connection | Pass-through (girth hitch) |
| Standards | ANSI Z359.18-2017; OSHA 1926.502 and 1910 |
| Packaging | Sold in multi-packs. Pack quantity is set per length so each pack is an economical order; choose your length and pack size in the options above. |
| Warranty | FallTech 2-year limited warranty against defects in materials and workmanship |
Frequently Asked Questions
FallTech CPTC Submittals and Documentation
7428 Instruction Manual (PDF)Installation, application limits, capacity, and inspection. 7428 Declaration of Conformity, ANSI (PDF)Certification to ANSI Z359.18-2017 (FallTech test lab). 7428 Spec Sheet (PDF)One-page specifications and compliance summary.Related Anchors
