FallTech Suspended Cable Anchor, Drop-Through, 2-8.5 ft

(No reviews yet) Write a Review
$127.50 - $148.00
Brand:
FallTech
SKU:
7494SC
Availability:
Usually ships in 1 business day
Shipping:
Calculated at Checkout
Adding to cart… The item has been added
American Express Icon American Express Icon Discover Icon Discover Icon Mastercard Icon Mastercard Icon PayPal Icon PayPal Icon Visa Icon Visa Icon
FallTech Anchorage Connectors

FallTech Suspended Cable Anchor for Drop-Through Installation

The FallTech Suspended Cable Anchor drops through a deck or roof opening and expands or toggles behind the structure to create an overhead tie-off point from below. The steel cable hangs down to a connection point at a comfortable working height. Choose the cable length for your ceiling or deck height.

It is certified to ANSI Z359.18-2017, rated for 5,000 lb (22.2 kN), for one worker up to 310 lb (ANSI) or 425 lb (OSHA). Sold in multi-packs.

FallTech suspended cable anchor for drop-through installation from below
5,000 lbsAnchorage Strength (22.2 kN)
Type AANSI Z359.18-2017
1 Worker310 lb ANSI / 425 lb OSHA
Drop-ThroughInstall From Below
Steel Cable2 ft to 8.5 ft
Overhead AnchorWorking-Height D-Ring
ReusableRemovable
Multi-PackContractor Quantities

Who Needs This Product

This product is a suspended cable anchor, the anchorage component of a personal fall arrest system installed from below through a deck or roof opening. Crews drop it through, seat it behind the structure, and connect an SRL or lanyard to the hanging cable end. Choose the cable length for your height. You still need a certified full-body harness and a compatible connecting device.

Features

Drop-through install

Sets from below through a deck or roof opening, no top-side access needed.

Working-height connection

The steel cable hangs to a D-ring at a comfortable height.

Choose the length

2 ft, 6 ft, or 8.5 ft cable to suit the ceiling or deck height.

Steel cable

Cut and abrasion resistant wire rope for a durable anchor.

Reusable

Remove and reuse the anchor per the manual.

ANSI Z359.18-2017

Certified anchorage rated for 5,000 lb (22.2 kN).

⚠

Seat fully behind a sound, rated structure per the manual. Confirm the deck or roof structure is rated to support the anchor, drop the anchor through the opening, and confirm it is fully seated behind the structure before use. Confirm fall clearance and swing-fall with the Fall Protection Calculator below.

Compliance Standards

ANSI Z359.18-2017

American National Standard for anchorage connectors. Rated 5,000 lb (22.2 kN).

OSHA 29 CFR 1926.502

Federal construction fall protection anchorage requirements.

OSHA 29 CFR 1910

General industry personal fall protection requirements.

Rated 5,000 lb (22.2 kN)

Anchorage strength for personal fall arrest.

Typical Applications

Overhead deck workTie-off installed from below.
Ceiling and roof accessAnchor through an opening.
IndustrialSuspended anchor for work under a deck.
MaintenanceReusable drop-through anchor.
PrecastAnchor through panel openings.
InspectionOverhead tie-off from below.

How to Install

Follow the FallTech instruction manual. The sequence below is an overview only.

  1. Inspect. Check the anchor body, connection point, and hardware for damage before each use.
  2. Prepare the structure. Confirm the mounting surface is sound and rated to support the anchor per the manual.
  3. Install and secure. Mount the anchor as specified and set all fasteners to the required torque.
  4. Connect. Attach your SRL or energy-absorbing lanyard to the connection point.
  5. Check clearance. Confirm fall clearance and swing-fall with the calculator below.

Inspection and Retirement

Inspect before each use, with a documented competent-person inspection at least annually. Remove the anchor from service for any of the conditions below.

  • Anchor body and welds: cracks, bending, deformation, or corrosion.
  • D-ring or connection point: deformation, sharp edges, cracks, or corrosion.
  • Fasteners and hardware: damaged threads, loose or missing fasteners.
  • Labels: illegible or missing markings.

Remove the anchor from service immediately after any fall-arrest event, and destroy retired equipment so it cannot return to service.

Fall Protection Distributors logo Fall Protection
Distributors, LLC Free Tool · No Signup · OSHA 1926.502 Free Interactive Tool Fall Protection Calculator Pick your system. Run the math. Generate a plan. 1Pick Your SystemDetermine fall restraint vs. fall arrest based on your work surface, edge access, and clearance. 2Run the MathCalculate exact fall clearance required below the work surface for your lanyard or SRL setup. 3Generate a PlanGet a printable OSHA-compliant Fall Protection Plan structured around 29 CFR 1926.502(k). Run the Numbers and Stay Safe Launch the Calculator ›

Technical Specifications

TypeSuspended cable anchor for drop-through installation
Cable lengths2 ft, 6 ft, 8.5 ft
MaterialGalvanized steel wire rope
Anchorage classificationANSI Z359.18-2017
Anchorage strength5,000 lb (22.2 kN)
Capacity (ANSI)One worker, 130 to 310 lb combined
Capacity (OSHA)One worker, up to 425 lb combined
StandardsANSI Z359.18-2017; OSHA 1926.502 and 1910
WarrantyFallTech 2-year limited warranty against defects in materials and workmanship

Frequently Asked Questions

How does a drop-through anchor install?
You drop it through a deck or roof opening and it seats behind the structure, so the whole install is done from below, with the cable hanging to a working-height connection.
What cable lengths are available?
2 ft (74942), 6 ft (74946), and 8.5 ft (749485); choose based on your ceiling or deck height.
What is the rated strength and capacity?
Certified to ANSI Z359.18-2017 with 5,000 lb (22.2 kN) strength, for one worker up to 310 lb (ANSI) or 425 lb (OSHA).
Is it reusable?
Yes. Remove and reuse the anchor per the manual once the work is complete.
Why is it sold in multi-packs?
Suspended anchors are used in quantity on overhead deck work, so they ship in contractor multi-packs.
What do I connect to it?
Connect a compatible SRL or energy-absorbing lanyard to the connection point, used with a certified full-body harness.
Can it be reused after a fall?
No. Remove the anchor from service immediately after any fall-arrest event and destroy it so it cannot be reused.

FallTech 7494SC Submittals and Documentation

74942 Instruction Manual (PDF)Installation, capacity, and inspection. 74942 Declaration of Conformity (PDF)Certification to ANSI Z359.18-2017 (FallTech test lab). 74942 Spec Sheet (PDF)One-page specifications summary.

Related Anchors

Specifying Anchors for Your Crew?

The anchor, the connecting device, and the harness all have to match the structure and the fall clearance below. Confirm your application with us and we will help you choose the right anchor.

Call 863-703-4522 to talk to a fall protection specialist.

FallTech provides a 2-year limited warranty against defects in materials and workmanship on the FallTech product. The warranty is void if the product is altered, misused, or damaged by neglect, abuse, or accident, and it excludes normal wear. Fall Protection Distributors, LLC passes through the manufacturer warranty and is not liable beyond the product replacement it provides.
