Seraph Construction Harness with Waist Pad, XS to XXL
The Guardian Seraph builds lumbar support into the harness: an integrated waist pad that spreads tool and suspension loads across the lower back, over pass-through chest and tongue-buckle leg buckles. Stocked in three sizes from XS-S (3711172) through XL-XXL (3711174), one of the few premium harnesses stocked down to extra small.
Certified to ANSI Z359.11 and compliant with OSHA 1910.140 and 1926.502 at the capacities in the manual.
Guardian Harness Sizing Chart
Height (ft) by Weight (lb)
Blocks overlap by design: in an overlap, either size fits. Approximate bands: Small 100 to 160 lb and 5 ft to 6 ft. M-L 130 to 240 lb and 5 ft to 6 ft 2 in. XL 180 to 300 lb and 5 ft 2 in to 6 ft 4 in. 2XL 240 to 360 lb and 5 ft 4 in to 6 ft 6 in. 3XL 300 to 420 lb and 5 ft 6 in to 6 ft 8 in. Guardian harnesses sold as Universal or S-L span the Small and M-L bands, and XL-XXL spans the XL and 2XL bands. Based on the manufacturer's published Guardian sizing chart; verify fit per the instruction manual before first use.
Who Needs This Product
The waist pad is the Seraph argument: workers who carry pouches or spend time in partial suspension feel lower-back load first, and the pad turns the harness waist into support instead of a pressure line. The XS-S size extends the premium fit range to smaller workers most lines ignore.
Features
Reliable safety performance
Full body harness designed to meet OSHA and ANSI Z359.11 standards, featuring durable construction with zinc-plated steel hardware for long-term use.
Built-in convenience
Dual auto-resetting lanyard keepers provide a reusable, convenient way to stow unused connector legs
Streamlined SRL connection and D-ring access
Slotted SRL adapter provides a secure connection point for self-retracting lifelines, helping reduce sag while keeping the dorsal D-ring clear and accessible
Integrated tool support and comfort
Durable waist pad with removable belt allows for tool bag attachment while providing all-day support and stability
Enhanced comfort and positioning
Breathable shoulder padding and side D-rings support all-day comfort and hands-free work positioning
Size
XS-S
Options in This Family
| SKU | Description |
|---|---|
| 3711172 | Guardian Seraph Harness with Waist Pad, PT Chest, TB Legs, XS-S |
| 3711173 | Guardian Seraph Harness with Waist Pad, PT Chest, TB Legs, M-L |
| 3711174 | Guardian Seraph Harness with Waist Pad, PT Chest, TB Legs, XL-XXL |
Technical Specifications
| SKU | 3711172 / 3711173 / 3711174 |
|---|---|
| Product weight | 3.5 lbs |
| Dimensions | 15 in L x 11 in W x 3 in H |
| Standards | OSHA 1910.140, 1926.502, ANSI Z359.11-2021 |
| Warranty | Guardian lifetime warranty against defects in material and workmanship |
Fit before the first step up. Adjust the harness so the dorsal D-ring sits between the shoulder blades, the chest strap crosses mid-chest, and leg straps allow a flat hand but not a fist. Retire any harness that has arrested a fall.
Compliance Standards
OSHA 1910.140
This product is compliant with OSHA 1910.140 when used as part of a complete, competent-person verified system.
1926.502
This product is compliant with 1926.502 when used as part of a complete, competent-person verified system.
ANSI Z359.11-2021
This product is compliant with ANSI Z359.11-2021 when used as part of a complete, competent-person verified system.
ISO 17025 lab tested
Guardian products are tested in an ISO 17025 accredited laboratory; available documentation is linked below.
Typical Applications
Donning Overview
Donning must follow the Guardian instruction manual for this harness. The sequence below is an overview only.
- Inspect first. Check webbing, stitching, D-rings, and buckles before every use.
- Shake out and orient. Hold by the dorsal D-ring; straps fall into place without twists.
- Arms through. Put the harness on like a jacket, shoulder straps over both shoulders.
- Buckle the chest. Connect the chest buckle at mid-chest height.
- Buckle the legs. Connect each leg strap; snug so a flat hand fits but a fist does not.
- Adjust and check. Set all adjustment points and confirm the dorsal D-ring sits between the shoulder blades.
Inspection and Retirement
Inspect before every use, and have a competent person perform a documented inspection at least every six months under ANSI Z359.2 practice. Remove the harness from service for any of the conditions below.
- Webbing: cuts, fraying, abrasion, burns, or chemical damage.
- Stitching: broken, pulled, or abraded threads at load-bearing junctions.
- Hardware: cracks, corrosion, or deformation of D-rings and buckles.
- Impact indicators: any deployment (models so equipped).
- Labels: missing or illegible.
Retirement triggers: any fall arrest event, a deployed impact indicator, or any condition where the inspector cannot positively verify the harness is fit for service.
