Cross-Arm Strap with D-Ring and Web Loop
The 8185 does the wrap-and-choke with a web loop instead of a second D-ring: pass the D-ring end through the loop, cinch onto the member, and clip in. The 3 ft length suits purlins, pipe, and standard structural members.
Built for portable, reusable temporary anchorage compatible with most fall protection systems, at the value end of the anchor strap range.
Who Needs This Product
The loop-style strap is the economical everyday anchor for crews that wrap the same size members all day: one fewer forging keeps cost down while the wrap-and-choke performance stays identical. Other lengths and the two-D-ring 8183 cover members outside the 3 ft wrap range.
Features
Loop-and-Choke Design
Pass the D-ring end through the web loop and cinch; the strap grips the member under load.
Rugged Webbing
Durable webbing built for repeated wraps on rough steel and concrete.
Integral D-Ring
The forged D-ring gives the connecting device a proper interface.
Portable and Reusable
Installs, moves, and reinstalls all day without tools.
Wrap-Around Fit
Adapts to beams and structural members within the wrap range.
System Compatible
Accepts snap hooks and carabiners from any compliant system.
Technical Specifications
| SKU | 8185/3FTGN |
|---|---|
| Product | Cross-Arm Anchor Strap, D-Ring and Loop |
| Length | 3 ft |
| Configuration | One D-ring, one web loop, choke-through |
| Webbing | Polyester, green |
| Standards | Meets OSHA and ANSI anchorage connector standards |
| Warranty | Miller Limited Lifetime Warranty against defects in workmanship and materials |
The anchor is only as good as the structure. Connect only to members that meet OSHA anchorage strength, position to minimize free fall and swing, and inspect before every use.
Compliance Standards
OSHA 1926.502 Anchorage
Anchorages for fall arrest must support 5,000 lb per worker attached, or maintain a safety factor of two under a qualified person.
ANSI Z359 Practice
Anchorage connectors follow ANSI Z359 component practice with 5,000 lb rated hardware.
ANSI Z359.2
Kept in service through pre-use checks and documented competent person inspections at least annually.
Typical Applications
Setup Overview
- Inspect the anchor and hardware before use.
- Select structure that meets OSHA anchorage strength for fall arrest.
- Install the anchor per the instructions for the structure type.
- Connect the lanyard or SRL and verify gates lock.
- Verify fall clearance and swing fall exposure before working.
Full installation instructions ship with the product.
Inspection and Retirement
Inspect before each use and have a competent person inspect at least annually per ANSI Z359.2.
- Webbing or body: cuts, frays, corrosion, cracks, distortion, or damage.
- D-rings and hooks: no cracks, corrosion, distortion; gates lock where fitted.
- Stitching and fasteners: intact and tight.
- Labels: present and legible.
Retirement triggers: any fall arrest loading, any defect found during inspection, or failure to verify fitness for service.
