Economy Polyester Visor - Clear, Flat (12-Pack)
The Malta Dynamics HHE840ME is an economy clear polyester flat visor measuring 8 inches by 15 inches by 0.04 inch, part of the Malta Dynamics hard hat mounted face protection line. It is used with Malta Dynamics face shield brackets to protect against light chemical splashes and impacts on the jobsite.
Brackets are available in several mounting styles that attach securely to Malta Dynamics hard hats and caps. The visor conforms to the ANSI/ISEA Z87.1-2010 standard for face protection when used in combination with Malta Dynamics headgear or face shield brackets. This listing is a 12-pack for stocking a crew with affordable replacement visors.
Who Needs This Product
This economy polyester visor is an affordable replacement face window for crews already running Malta Dynamics hard hat face shield brackets, used against light chemical splashes and impacts. It is a secondary protector: it works only in combination with a Malta Dynamics face shield bracket or headgear, which are sold separately, and it must be worn with ANSI Z87.1 approved goggles or safety glasses underneath. For higher heat or impact, choose the heavier acetate or Tritan visors.
Features
Economy polyester
An affordable clear polyester visor for light-duty face protection and high-volume replacement.
Light splash and impact
Protects against light chemical splashes and impacts when used with a face shield bracket.
Standard 8 x 15 size
A flat 8 in by 15 in by 0.04 in window that fits Malta Dynamics face shield brackets and headgear.
Bracket compatible
Works with Malta Dynamics face shield brackets in several mounting styles for hard hats and caps.
ANSI Z87.1 compliant
Conforms to ANSI/ISEA Z87.1-2010 for face protection when used with Malta Dynamics headgear or brackets.
Crew-pack value
A 12-pack keeps low-cost replacement visors on hand for the whole crew.
Technical Specifications
| SKU | HHE840ME-14PK (single SKU HHE840ME) |
|---|---|
| Pack quantity | 12 visors |
| Type | Hard hat mounted face protection visor (secondary protector) |
| Material | Economy polyester |
| Color | Clear |
| Shape | Flat |
| Dimensions | 8 in x 15 in x 0.04 in |
| Weight (each) | 0.24 lb |
| Mounting | Malta Dynamics face shield brackets (sold separately) |
| Use with | Malta Dynamics hard hats, caps, or headgear |
| Primary protection required | Wear with ANSI Z87.1 goggles or safety glasses |
| Compliance | ANSI/ISEA Z87.1-2010 (with Malta Dynamics headgear or brackets) |
| Warranty | 1 year limited (Malta Dynamics) against factory defects in workmanship and materials |
A visor is secondary protection used with a bracket. This visor conforms to ANSI Z87.1 only when used in combination with a Malta Dynamics face shield bracket or headgear, which are sold separately. Always wear ANSI Z87.1 approved goggles or safety glasses with face shield frames and visors for maximum protection. The economy polyester visor is for light splash and impact; choose acetate or Tritan for higher heat or impact.
Compliance Standards
ANSI/ISEA Z87.1-2010
American National Standard for occupational eye and face protection; the visor conforms when used with Malta Dynamics headgear or brackets.
OSHA 29 CFR 1910.133
OSHA eye and face protection requirement for general industry.
Secondary protector
Designed to be worn over primary eye protection such as goggles or safety glasses.
Bracket-mounted system
Compliance applies to the visor used with a compatible Malta Dynamics bracket and headgear.
Typical Applications
Installation Overview
Install and use per the Malta Dynamics hard hat face protection instructions. The sequence below is an overview only.
- Inspect. Check the visor for cracks, scratches, or warping before each use.
- Mount the bracket. Install a Malta Dynamics face shield bracket (sold separately) on the hard hat or cap.
- Attach the visor. Secure the 8 x 15 visor to the bracket per the bracket instructions.
- Wear primary protection. Put on ANSI Z87.1 goggles or safety glasses under the visor.
- Position. Lower the visor for the task and raise it when not needed.
- Replace as needed. Swap in a fresh visor from the pack when one is scratched or damaged.
Inspection and Retirement
Inspect before each use. Remove the visor from service for any of the conditions below.
- Visor: cracks, deep scratches, or warping that impairs vision or protection.
- Edges: chips, splits, or distortion at the mounting edge.
- Clarity: clouding or chemical hazing from exposure.
- Fit: a visor that no longer seats securely in the bracket.
- Damage: any sign of impact or chemical degradation.
Retirement triggers: any forcible impact, any cracked or chemically degraded visor, or any visor that no longer mounts securely. Because this is an economy replacement visor, swap it out promptly at any sign of wear.
